Regulators of low pressure series are available in several different configurations and connectors size. They are made, as well as the meter for which they are intended, in line and coaxially version. Lower pressure lock (LPCO) can be ordered optionally. Alternatively, these controllers can be equipped with a system to stop the flow due to gas leakage. Regulators are fire-resistant and approved in accordance with the standards and DVGW VP 200.
60DJ, 80DJ & 150DJ
The Elster Jeavons APPLIANCE Regulators are compact and economical. They are suitable a wide range of domestic appliance and pilot applications with inlet pressures up to 100mbar (40"wg). They comply with the Essential Requirements of the European Gas Appliance Directive (90/396/EEC). All units are designed for natural, liquefied petroleum and manufactured gases and can be installed in vertical ...
Low pressure regulatorsElster GmbH
HR
HR series of service regulators for use with several meters in small, medium and large consumption units. Diameters DN 25, 32, 40, 50, 80, 100 Inlet pressure up to 100 mbar Outlet pressure range 18 - 50 mbar Inlet pressure resistance up to 16 bar
Low pressure regulatorsElster GmbH
J42
The J42 is an angled type regulator designed for low pressure domestic meter applications with inlet pressures up to 350 mbar. It uses well proven principles of control dynamics together with modern assembly techniques to produce a regulator which offers excellent performance in a compact, low cost, maintenance free unit. Sizes: 3/4" x 3/4" and 3/4" x 1” Inlet ...
Low pressure regulatorsElster GmbH
J48 (2½ up to 6 inch size)
The J48 is an industrial low pressure regulator suitable for a wide range of pressure reduction applications, including such OEM equipment as boiler and burner trains for a variety of gases. • Sizes: 2 1/2", 3", 4" & 6". • Inlet pressure up to 350 mbar. • Outlet pressure up to 160 mbar (2 1/2" - 3"). • Outlet pressure up to 345 mbar (4” - ...
Low pressure regulatorsElster GmbH
J48 (up to 2 inch size)
The J48 is an industrial low pressure regulator suitable for a wide range of pressure reduction applications, including such OEM equipment as boiler and burner trains for a variety of gases. Sizes: 3/4", 1", 1 1/4", 1 1/2" & 2" Inlet pressure up to 350 mbar. Outlet pressure 5 to 160 mbar (2" up to 100 mbar). Temperature range -20 to +70 °C Quick release spring change facility ...
Low pressure regulatorsElster GmbH
J78
The J78 range is a compact, accurate and economical regulator. It is suitable for a wide range of commercial and industrial applications such as boiler and burner trains. The J78 is available in a number of sizes, with a comprehensive range of regulator springs for different requirements. The J78 range is suitable for inlet pressures up to 350 mbar (5 psig). It meets the essential requirements ...
Low pressure regulatorsElster GmbH
J90
The J90 is a dedicated angle regulator designed to give accurate control, even at low pressure differentials, with excellent reliability. The J90 is a meter service regulator suitable for a wide range of commercial and industrial applications. All units are designed for natural, liquid petroleum and manufactured gases. The J90 has been designed for high efficiency and sensitivity with maximum ...
Low pressure regulatorsElster GmbH
NDAF
NDAF series of co-axial service regulators for use with several smaller units.Installation is via special co-axial connectors. Diameters DN 25, 40, 50 Inlet pressure up to 100 mbar Outlet pressure range 18 - 50 mbar Inlet pressure resistance up to 16 bar
Low pressure regulatorsElster GmbH
ZR(E)
The ZR series of meter service regulators for low-pressure applications and for use with gas meters is available with or without an integrated low-pressure cut-off valve (LPCO). Diameters DN 20, 25, 32, 40 Inlet pressure up to 100 mbar Outlet pressure range 18 -50 mbar Inlet pressure resistance up to 16 bar
Low pressure regulatorsElster GmbH
ZRH
ZRH series of meter service governors for use with high-performance two-pipe gas meters(BK-G25), includes compensating pipe for vertical installation. Diameter DN 50 Inlet pressure up to 100 mbar Outlet pressure range 18 -50 mbar Inlet pressure resistance up to 16 bar
